♦7’’ touch screen
♦Back spectro photometry
♦7 standard filters
♦Built-in thermal printer,USB for external printer
Back spectro photometry, 7 hard membrane filters, separate signal process circuit for each wavelength, filters select completed electronically,no mechanical movement
Hermetic solid-state optical system, low contamination of dust and dampness, long life time of hard membrane filters
Titanium alloy flow cell with small capacity and minimize cross-contamination
200000 patients test data and 300 test programs can be saved
Adopt 7’’touch screen,800×480pixels
|
Analysis method |
kinetics, end point, two point, multi-point. |
|
Light source |
halogen lamp 10w/6V, |
|
Optical system |
340-800nm |
|
7 standard filter |
340, 405, 492, 510, 546, 578, 630nm wavelength, accuracy:±2nm |
|
Abs range |
0.000-4.000Abs, resolution:±2nm |
|
Flow cell |
titanium quartz alloy, 33uL; optical path: 10mm |
|
Temperature |
PELTIER elements, 37℃,Room±0.1℃ |
|
Precision |
error<1%, drift<5mAbs/hr |
|
Printer |
thermal printer, 57mm width paper |
|
Display |
7’’touch screen,800×480pixels |
|
CPU |
Samsung S5PV210, Cortex-TM-AB,1GHZ |
|
Memory |
DDR2 SDRAM,256MB Flash:4GB |
|
Interface |
3 USB ports,1 RS232 serial port |
|
Dimensions |
380(L)x280(W)x170(H)mm |
|
Weight |
5Kg(net), 6Kg(gross) |
