Dexa Bone Densitometer-Henan forever Medical Co., Ltd.

Dexa Bone Densitometer

Features:

1. Using the Dual Energy X-Ray Absorptimetry.

2. Using the Most Advanced Cone – Beam and Surface Imaging Technology.

3. With High Measurement Speed and Short Measurement Time.

4. With Dual Imaging Technology to Get More Accurate Measurement.

5. Using Laser Beam Positioning Technique, Making the Measuring Position More Accurate.

…

Dual Energy DEXA Absorptiometry Bone Densitometer Radiology Equipment

Diagnostic Scan

More Convenient

Measuring Bone MineralDensity or Bone Strength of the People's Radius and Tibia. It is for Preventing Osteoporosis

Our - have extensive application

it used for Maternal and Child Health Centers,Geriatric Hospital, Sanatorium, Rehabilitation Hospital,Bone Injury Hospital, Physical Examination Center, Health Center, CommunityHospital,Pharmaceutical factory, Pharmacy and Health Care Products

Features:

1. Using the Dual Energy X-Ray Absorptimetry.

2. Using the Most Advanced Cone - Beam and Surface Imaging Technology.

3. With High Measurement Speed and Short Measurement Time.

4. With Dual Imaging Technology to Get More Accurate Measurement.

5. Using Laser Beam Positioning Technique, Making the Measuring Position More Accurate.

6. Dectcing Image Digitization, to Get Accurate Measurement Results.

7. Adopting the Surface Imaging Technology, Measuring Faster and Better.

8. Using the Unique Algorithms to Get More Accurate Measurement Results.

9. Adopting the Full Closed Lead Protective Window to Measure, only Need to Put the Patient's Arm into the W The Equipment is
indirect Contact with the Scanning Parts of the Patient. Easy to Operate for the Doctor. It is Safety for the Patient and Doctor.

10. Unique Shape, Beautiful Appearance and Easy to U

Technical specifications

Measurement Parts	the Front of Forearm. 1/3 of distal radius
X ray tube voltage	High Energy 70 Kv, Low Energy 45Kv.
The high and low energy corresponds to the current,0.25 mA at high energy and 0.45mA at low energy
X-Ray Detector:Imported HighSensitivity Digital Camera.
Imaging Way	Cone - Beam and Surface Imaging Technology
X-Ray Source	Stationary Anode X-ray Tube (with High Frequency and Small Focus)
Imaging Time	≤4
Accuracy(error)	≤4%
Repeatability Coefficient of Variation CV	≤0.25%
Measuring Area	>=150mm*110mm
Can be connected to hospital HIS system, PACS system
Provide WorklistPort with independent upload and download function
Measuring Parameter	T- Score, Z-Score, BMD,BMC,Area,Adult percent[%], Age percent[%], BQI (The Bone Quality Index) ,BMI,RRF:Relative Fracture Risk
It with multi race clinical database, including	European, American, Asian, Chinese, WHO international compatibility. It measuring the people between the age of 0 and 13
Measuring children over three years older
Original Dell Business Computer: ,Intel i5,Quad Core Processor ,8G,1T,22'inch HD Monitor
Operation System	Win7 32-bit / 64 bit ,Win10 64 bit compatible
Working Voltage	220V±10%, 50Hz.
