Laptop Color Doppler Ultrasound Scaner

12 inches HD LCD Displayer;
Based on Windows 7 platform operation system;
Dual transducer interface;
Imaging mode B、B+B、4B、B+M、PW、CFM、B+CFM、PDI、B+PDI
3D software pre-installed;
THI imaging technology;
Support 7 kinds languages(CN\EN\RUS\POR\ESP\FR\DE);
IMT automatic measure function;
3200mAh chargeable battery with management;

Laptop Type Color Doppler Ultrasound Scanner--YJ-E20

Product Description

Main Features:

* 12 inches HD LCD Displayer;
* Based on Windows 7 platform operation system;
* Dual transducer interface;
* Support convex、linear、endocavitary、micro-convex and transrectal probe;
* Imaging mode B、B+B、4B、B+M、PW、CFM、B+CFM、PDI、B+PDI
* 3D software pre-installed;
* THIimaging technology;

* Support 7 kinds languages(CN\EN\RUS\POR\ESP\FR\DE);
* IMT automatic measure function;
* Editable report page;
* Support HDMI、VGA、DICOM、USB、LINE OUT;
* Equipped solid state drive, make the storage safer and more reliable;
* Environmental protection and low power consumption design;
* 3200mAh chargeable battery with management;

Technical specifications

YJ-E20 Laptop Color Doppler Ultrasonic Diagnostic System
Main Feature	Laptop thin and light design;
	12.1'' LCD Displayer;
	Windows 7 operation system;
	Standard key board and backlight key;
	3200mAh recharge lithium battery.
Main Parameter	Display modes: B、 B/B、4B、B+M、CFM、B+CFM、PDI、B+PDI、PW;
	Gray scale: 256 levels,
	5 levels image optimization; THI imaging technology;
	THI imaging technology;
	Rich image processing technology, for instance frames average, view angle, edge enhance, Gamma ,etc
	CN,EN,RUS,POR,ESP,FR,DE 7 kinds languages;
	Display penetration depth 1~400mm;
	Dynamic range: 80~280dB adjustable;
	Application mode OB,GYN, Small organ, Urology, Pediatric, Cardiac etc;
	Preset the parameter depend on scanning organ;
	IMT automatic measurement and display results;
	15 kinds of pseudo color;
	Support guide line of biopsy puncture;
	Built-in 120G soild state drive ,make the storage safer and more reliable;
	Support frequency conversion range: 2MHz~12MHz (depend on probe type);
	Built-in editable report page ;
	Gain control: 8 segments TGC and overall gain can be adjusted respectively;
	Focus position: dynamic electron focusing.
Interface ports	2 activated probe connector
Interface ports	Interface Port: HDMI, VGA, DICOM, USB, Line Out.
Optional Probe	Convex
	Trans-vaginal
	Linear
	Micro-convex
