Heart Ultrasound

*Main screen 15″ medical HD monitor

*Flexible monitor bracket

*All-in-one keypad

*Detachable probe hanging slot

*Front double pull handle

*Flexible caster, directional locking

*One-piece body structure

Full Digital Ultrasound System Sonography Machine YJ-370

IMAGE PROCESSING FUNCTION --- PSEUDO COLOR

It is a way to change the display mode of black and white images into color display.

PSEUDO COLOR

Since the human eye is not very sensitive to the resolution of gray scale levels, the sensitivity of the human eye to different echo intensities can be enhanced after the black and white images are converted to color. Subjectively, the dynamic range of the display signal is increased, and the recognizability of the image boundary is enhanced.

.Main screen 15" medical HD monitor

.Flexible monitor bracket

.All-in-one keypad

·Detachable probe hanging slot

.Front double pull handle

.Flexible caster,  directional locking

.One-piece body structure

Optional Accessories

Special sheet metal custom printer placement box, convenient and practical, solid and reliable, effectively solve the problem of space placement.

5200mAH built-in battery, 2-3 hours endurance operation, easy to move in various clinical application scenarios.

Rich transducers

Clinical Images

cardiac echo sonographer

Main specifications

Application description and cargo requirements:
Meet the examination and diagnosis of primary hospitals in abdominal, obstetrics, gynecology, heart, urinary system, small organs, superficial, blood vessels, pediatric physical examination and other aspects.

Main specifications and system overview:

Operating system: based on ARM System, stable, simple and power
Support three probe sockets, which can select the inspection site
Display mode: B, B+B, B+M, M, 4B;
Display screen: 15-inch 1024*768 resolution high-definition LED LCD screen
System language: Chinese and English, Spanish, French
machine size: 579.1 * 710.69 * 1220.33mm
Net weight: 46 kg

Probes:

Convex array probe (C3-2): frequency 2.0MHz/2.5MHz/3.5MHz/5.0MHz/,
four-stage frequency conversion, the center frequency is 3.5MHz,
each frequency conversion corresponds to the corresponding harmonic frequency
(depth adjustment: ≥19 level, adjustment range 50-280mm)

Linear array probe (L3-2): frequency 6.5MHz/7.5MHz/8.5MHz/9.0MHz,
four-stage frequency conversion, the center frequency is 7.5MHz,
each frequency conversion corresponds to the corresponding harmonic frequency
(depth adjustment: ≥6 levels , adjustment range 50-100mm)

Transvaginal probe (EC1-2): frequency 4.0MHz/5.0MHz/6.5MHz/8.0MHz,
four-stage frequency conversion, the center frequency is 6.5MHz,
each frequency conversion corresponds to the corresponding harmonic frequency
(depth adjustment: ≥6 levels , adjustment range 50-100mm)
